Digitization of an engineering part with complex geometry
3D Modeling
Creation of a technical 3D model of a casing part based on a drawing.
• Complexity: Working with inclined planes, deep grooves, and precise surface fittings.
• Tools: Using professional software Creo Parametric to ensure perfect dimensional accuracy.
• Result: A finished engineering model that can be used in assemblies or sent for production (CNC/printing).
