Device for control and management of ACS on OrangePi
Control and management device for access control system (turnstile at the checkpoint and access to 4 rooms) based on OrangePi, running Ubuntu and scripts in Python.
The device is available for connection via local network, it has a web server with a database that displays its status and the status of all connected devices in real-time.
The chassis is designed for integration into a 19" server box.
Control of the access devices (4 rooms) is done via RS485 protocol (modbus), powered by passive-PoE, with RJ-45 connectors.
In the photo, the case and front panel of the device are made from aluminum strip. The indicator porthole (insert) is made from acrylic. All parts, except for the steel chassis, are machined on our own CNC machine.
The device is available for connection via local network, it has a web server with a database that displays its status and the status of all connected devices in real-time.
The chassis is designed for integration into a 19" server box.
Control of the access devices (4 rooms) is done via RS485 protocol (modbus), powered by passive-PoE, with RJ-45 connectors.
In the photo, the case and front panel of the device are made from aluminum strip. The indicator porthole (insert) is made from acrylic. All parts, except for the steel chassis, are machined on our own CNC machine.
